Stability Chambers for Pharmaceutical Applications | Affordable & Compact Models
Stability chamber price and performance matter. We offer reliable small chambers for pharmaceutical testing with precise humidity and temperature control.
Together With Committees From The Pharmaceutical Industry, Experts From The Licensing Authorities (such As The FDA) Have Developed The Ich Guidelines For The Harmonization Of Stability Tests. These Guidelines Define Standardized Storage And Batch Evaluation As Well As The Time Sequence Of The Required Analytic Tests.
Stability Chambers for Pharmaceutical Applications | Affordable & Compact Models
Temperature Range: 0 °C to 80 °C
Humidity Range: 30%rh To 98%rh
Features:
Non-condensing Steam Injection-type Humidity System With Stand-by System And Auto Switch Over
Forced Air Circulation for Uniform Temperature Across the Chamber
Low And High Temperature Cut-off Settable Thermostats& High Humidity Cut-off Thermostats.
Test Conditions like:
1, long-term test:25℃±2.0℃60%R.H±5%R.H 365 days
2, acceleration test:40℃±2.0℃75%R.H±5%R.H 180 days
3, mid-term test:30℃±2.0℃65%R.H±5%R.H 180 days
Technical Parameters
| Model | TH-80 | TH-150 | TH-225 | TH-408 | TH-800 | TH-1000 |
| Internal Dimension | 400x500x400 | 500x600x500 | 600x750x500 | 600x850x800 | 1000x1000x800 | 1000x1000x1000 |
| WxHxD (mm) | ||||||
| External Dimension | 950x1650x950 | 1050x1750x1050 | 1200x1900x1150 | 1200x1950x1350 | 1600x2000x1450 | 1600x2100x1450 |
| WxHxD (mm) | ||||||
| Temperature Range | T min: Low Temperature (A:25℃ B:0℃ C:-20℃ ) | |||||
| T max: High Temperature (80℃ ) | ||||||
| Humidity Range | Optional: ( 20%~98%R.H /10%-98% R.H. / 5%-98% R.H ) | |||||
| Analytic Accuracy/ | 0.1℃; 0.1% R.H/±2.0℃; ±3.0% R.H. | |||||
| Distribution uniformity | ||||||
| of temperature | ||||||
| and humidity | ||||||
| Control Accuracy | ±0.5℃; ±2.5% R.H. | |||||
| of Temperature and | ||||||
| Humidity | ||||||
| Temperature Rising/ | The temperature is rising approximately. 0.1~3.0℃/min | |||||
| Falling Speed Rate | The temperature is falling approximately. 0.1~1.5℃/min; | |||||
| Customizable | The Falling Speed Rate Min . 1.5℃per minute is a special optional condition | |||||
| Material | The material of the inner box is SUS 304# stainless steel, of the outer box is stainless steel or |
|||||
| SEE cold-rolled steel with paint coated. Insulation material is resistant to high temperatures. | ||||||
| high-density, formate chlorine, ethyl acetate foam insulation materials | ||||||
| Cooling System | Wind cooling or water cooling/single segment compressor(-40℃, double segment | |||||
| compressor -70℃) | ||||||
| Protection Devices | Fuse-free switch, overloading protection switch for compressor, high and low voltage | |||||
| coolant protection switch, over-humidity and over-temperature protection switch, fuses, | ||||||
| fault warning system, water shortage storage warning protection | ||||||
| Optional Accessories | Inner door with an operation hole, Recorder, Water Purifier, Dehumidifier | |||||
| Compressor | French Tecumseh Brand, Germany Bizer Brand | |||||
| Power | AC220V 1ph 3 lines, 50/60HZ , AC380V 3ph 5 lines , 50/60HZ | |||||
| Approx. Weight (Kg) | 150 | 180 | 250 | 320 | 400 | 450 |
